PAX IM30 Revolutionize Your Unattended Transactions Android Smart OS Running Android 7.1 OS, the IM30 is an all-in-one payment device providing payment acceptance and value-added business applications. Sunlight - readable Display Unique display technology to significantly enhance viewing even in direct or bright sunlight.
- Largest screen ever, 5-inch
- High resolution, 720 x 1280 pixels
- PIN -on-Glass technology
Omni-payment Solution Fastest Integration The IM30 meets EVA standard, which means it can be integrated easily with your existing infrastructure. Communication Interface IM30 provides a full set of connectivity and connections including 4G, WiFi, LAN, MDB, Bluetooth, USB and RS232, perfectly covering most vending system requirements. Impressive features Low-power Consumption
The low-power design allows the IM30 to be used in power-limited environments , and the intuitive proximity sensor supports smart energy consumption by switching between different states.

Front camera
The high resolution camera helps improve customer service such as push-to-talk , picture surveillance and protect your assets by identifying important customers or potential perpetrators with various Android software.
Innovative Self-Service Experience Buy online, pick up at vending Ideal Unattended Solution
Reliable

  • low failure rate over years
  • highest quality of components
  • the highest resistance to external conditions
Innovative

  • colour touch display with PIN entry mode
  • contact, contactless and magstripe card reader
  • QR and barcode reader
Integrated

  • many integrations and communication means available
  • compatible with EVA standard
  • working with MDB protocol
Multiple use cases

  • payment application
  • specialised industry applications
  • remote manage your business

Technical Specifications

Operating System

PayDroid, Powered by Android 7.1

Display

5-inch TFT Color Touchscreen
720 x 1280 pixels, IPS
Brightness > 600 nits

peripheral ports

2 x RS232
1 x USB Host
1 x USB OTG
1 x LAN
1 x MDB Slave
1 x Digital I/Os
1 x Mic & Speaker
1 x MDB Master & Executive
1 x SMA (opcjonalne)
1 x SIM Slot (opcjonalne)

Communications

4G + Ethernet + Wi-Fi® 24GHzZ/5GHz-+ Bluetooth® 5.0
Ethernet + Wi-Fi® 2.4GHz/5GHz + Bluetooth® 5.0 (optional)
Ethernet-Only (optional)

Certification

PCI PTS 5.x, SRED, EMV L1 & L2,
EMV Contactless L1, Mastercard contactless,
Visa payWave, American Expresspay,
Discover D-PAS, Mastercard TQM,
Interac Flash L2, J/Speedy L2, FCC, IC,
UL, RoHs, CE, CSEC, APCA

Processor

Quad-core Cortex-A53, 1.2 GHz

Camera & QR Scanner

Camera: 2.0 MP
QR Scanner : 0.3 MP Reads 1D & 2D Codes

Keypad

1 x Reset Key
1 x Service Key

Physical

External dimension:
WxHxD: 105 x 146 x 57mm
Installation Cutout:
W x H: 82 x 107 mm
Weight: 486g

Environmental

Operating temperature:
-20°C ~ 70°C (-4°F ~ 158°F)
Storage Temperature
-30°C ~ 70°C (-22°F ~ 158°F)
5% ~ 95% Relative Humidity,
Non-condensing

Memory

8GB Flash + 1GB LPDDR3
2GB LPDDR3 (optional)

Card Readers

Magnetic Card Reader
Smart Card Reader
Contactless Card Reader

Audio

1 x Speaker

SAM slots

2 (extendable to 4, optional)

Power

12V – 48V DC via MDB Slave
12V – 48V DC via RS232
19V – 30V AC via Executive
